Industrial Manufacturers

Solutions
– Field Assembled Air Preheaters
– Pre-Assembled Air Preheaters
– Gas-Gas Heaters
– SO3 Removal Technology
– Rotary Bed Adsorber
– Platforms and Anode Cages
– Specialized Fabrication
– Fuel Cell Thermal Manageme

Optimize your efficiency with AdvX Technology
– Maximize recovery and utilization of waste heat from flue gas
– Increase boiler efficiency, improved heat rate, lower coal consumption per kWh
– Cleaner emissions with improved ESP efficiency and lower SO3 emissions

Reduce costs and consumption
– Reduce costs thanks to increased operation flexibility
– Reduce sootblower steam consumption and no air preheater fouling

Improve your operations
– Extend air preheater element life
– Increase SCR catalyst life

Aid the environment
– Clear Stack
– Ultra-low emissions
– Reduce CO2, NOx, SOx, PM and Hg emissions
– Reduce FGD water consumption
– Reduce or eliminated waste water

Sedimentation Separation Equipment

• Clarifiers (Segmented, Spiral, Suction Header/Pipe)
• Solids Contact Clarifiers, Cold Lime Softeners (CLS)
• Thickeners

Biological Process Equipment

• Digester Covers
• Sequencing Bath Reactors (SBR)
• Bullseye Oxidation Channel
• Dissolved Air Flotation (DAF)
• Trickling Filters

Filters & Separators

• Disc Filters
• Walnut Shell Filters
• Oil Water Separators

Drives

• Retofits/Replacements of other brands
• Cage/Shaft Drives
• Dual Cage/Shaft Drives
• Multi-Pinion Cage/Shaft Drives
• Hydraulic Drives
• 5-year warranty (less motor & paint)
• 10-year warranty main gear

Company Highlights

• Over 1,800 mechanisms installed in 46 states and 19 countries.
• Built the world’s largest suction head clarifier at 220 ft diameter.
• 3D models for every project.
• 23 years of service.

Former Employees of WesTech Engineering that now work at ClearStream (years at WesTech)

• Jeff Easton, PhD Chemical Engineer, Senior Process Engineer (35 years)
• Jim Woods, Industrial Sales Manager (22 years)
• Ryan Arbuckle, International Sales Manager (18 years)
• Travis Zurcher, Applications Engineer (12 years)
• Larry Debirk, International Sales Manager (8 years)

Bottom Ash
Our patented Remote Submerged Scraper Conveyor (RSSC) can dewater your bottom ash slurry lines to aide in pond elimination. Our modular Submerged Scraper Conveyor (SSC) can be used to replace your existing wet bottom ash hopper.

Fly Ash
Our vacuum and pressure pneumatic conveying systems can be used to move product to dry storage silos with unloading and aeration systems.

Rotary Valves
Manufacture a complete line of rotary valves (air locks) used to meter flow of ash, coal, limestone and other abrasive materials. Our material handling valves are used on vacuum ash systems.

PERMA/flo
Manufacture abrasion resistant pipe and fittings (elbows) for the pneumatic conveyance of abrasive dry bulk materials.

Emission Control
Our patented flow splitting technology has been used in over 200 sorbent injection systems to reduce stack emissions. We provide mercury reduction systems and other dry sorbent injection (DSI) systems.

Fuel Transfer
Pneumatic fuel transfer & feed systems for coal, coke, alternative fuels.

FGD & Environmental Compliance
Custom engineer systems for hydrated lime, trona carbon, sodium bi-carbonate.

​Storage Silos and Unloading
We provide shop erected or field erected storage silos, silo unloading systems for both wet and dry unloading chutes into trucks/railcar and silo aeration systems.

Knife Gate Valves
Designed specifically for on/off pipeline isolation in high pressure pneumatic conveying applications.

Made in the USA
All Delta Ducon equipment and pipe is designed and manufactured in the USA.

• Fox engineers have 40 years of experience, using cutting-edge software tools.
• Dampers are designed for three primary functions: isolation, modulation, or diverting.
• Steel Stacks are custom designed for performance and cost.
• Fabric Expansion Joints to relieve the stress caused by constant or enduring system movement — directly mounted on our dampers to minimize field erection costs.
• Fox Equipment offers Silencers and Noise Control products. Fox Equipment Silencers are employed at the inlet and outlet of industrial fans and on the discharge of turbine exhaust systems to reduce noise emissions to acceptable levels. Fox Equipment designs and manufactures silencers to meet specified noise levels while staying within pressure drop limitations.
• For Turbine Exhaust, we now offer any component or a complete package including:  Diverter, Expansion Joints, Silencer and Stack.
• Heavy Duty Expansion Joints can replace OEM joints to reduce unplanned installations due to premature failure.
• Repair and Replacment Parts for our equipment and others.
• High-quality stainless steel liners to handle temperatures of over 1200°F.
• Every Fox Equipment product is Custom Designed & Engineered to exceed the expectations of its application and the expectations of our customers.
• 100% Solidworks for our CAD design.

• Engineers and manufactures the leading Medium Voltage Drives with the word’s largest installed base and overall portfolio in the industry.
• VFD drive systems match perfectly with our high-voltage motors.
• Provides unparalleled levels of reliability, availability, flexibility and performance.
• Optimally engineered for a wide range of industries and applications such as: conveyors, pumps, fans, compressors.
• Specialized applications include:  rolling mills, horizontal mills, shaft generators, high-speed compressors.
• Advanced features:  cell bypass, cell redundancy, warning systems, dynamic braking.
• Note the Definition of a Medium Voltage Drive
  • 2300 Volts to 13.8 KVolts
  • More than 250 HP (typically more than 400 HP)

Clyde Industries is a spin-off company from the Clyde Bergemann Power Group. It is the leading provider of boiler efficiency solutions for demanding applications in the pulp & paper, power and other industrial markets.

• Boiler Cleaning & Efficiency Solutions
  • • Wall Blowers
    • Soot Blowers
    • Water Cannons
• Spare Parts for:
  • • Clyde Industries
    • Copes Vulcan
    • Diamond Power
• Economizer, Convection Pass Cleaning Solutions
• SCR Cleaning Solutions
• Advanced Control Systems for Soot Blowers
• 60 years of experience in the Power Industry

Turnkey Solutions

• Turnkey solutions from consulting to tank design & engineering, custom manufacturing.
• Certified installation executed by UIG construction teams and post-installation service & support.
• Manages all aspects of a project including tanks, foundations, and custom covers.

Bolted Storage Tank Systems

• EVERSTORE Glass Fused-to-Steel
  • Using Titanium Rich Steel (TRS) for superior tensile strength, corrosion protection and adhesion.
  • All openings, nozzles, and bolt holes are laser-cut at the factory prior to enameling!
  • UIG only uses premium Grade 8 tank bolts sourced in North America and upgraded USS washers.
  • Optional Bolted Glass-Fused-to-Steel Floor for leak free tank floors.
  • Built to last, UIG Tank Systems rarely require any professional service or maintenance.
• ELITESTORE Stainless Steel
• ECOSTORE Fusion Bonded Epoxy
• Vinyl Decorative Wraps

EVERDOME Geodesic Domes & Custom Reservoir Covers

• Aluminum Geodesic Domes
• Glass-Fused-to-Steel or Stainless-Steel Conical Steel Roofs
• Clear Span Flat Panel Roofs – ideal for large-scale reservoir applications
• Internal Floating Roofs

Company Highlights

• Since 1969, UIG Tank Systems has led the industry in developing the world’s most advanced and longest-lasting bolted storage tank solutions.
• Leveraging 55+ years of R&D as a privately owned & operated company, UIG’s products are manufactured with premium materials and are meticulously designed for each client.
• UIG sets the industry standard for speed, efficiency, and quality.

Highlights of Shincci

• Low temperature (75F) sludge drying/dehumidification solutions using patented heat pump technology
• No flame – No explosion risks
• Shincci has over 1,600 installations globally, 800+ employees
• Typical payback is 3 years if spending $50/ton to dispose of waste
• 1/3 the capital costs of traditional drying
• 1/4 the energy costs of traditional drying
• Mobile/Pilot units available for trial

Applications

• Mesh Belt Drying (sludge treatement)
• Multi-Chamber Evaporation (milk, glucose, starch, chemicals, solvent recovery)
• Pyrolysis Machines (sludge, straw, fruit, shell)
• Container Batch Drying (seed, food, tobacco)
• Tower Grain Drying (grain crops, drying for siloing)

Mercury Reduction

• Calgon Carbon is committed to helping plant owners and operators meet increasingly stringent environmental regulations in the most economical way possible.
• FLUEPAC combines high adsorption capacity for exceptional mercury removal rates and low carbon usage rates.
  • Excel with capture rates over 90%
  • Preserve Fly Ash
  • Designed with better densities for mercury adsorbtion
• With five patents for FLUEPAC technology from the U.S. Patent & Trademark Office, Calgon Carbon is a proven innovator in the field of mercury removal.

Refinery / Industrial

• In addition to industrial potable water and water reuse, Calgon Carbon provides products, services, and equipment for a wide range of chemical and industrial processes.
• Within the gas industries – including natural gas and other high purity gases – refineries depend on our activated carbons to remove contamination. The liquefied natural gas industry uses our activated carbon products to remove mercury compounds that would otherwise corrode process equipment. Calgon Carbon’s activated carbons are also widely used in gasoline vapor recovery equipment.
• Calgon Carbon also provides activated carbon products and services that can effectively decolorize and purify certain chemicals, such as hydrochloric acid, and provide catalysis for reaction stages We pride ourselves in developing effective and innovative solutions for your industrial and commercial manufacturing processes.

Food & Beverage

• Even when the incoming process water is from a municipal drinking water source, the water may contain trace organics and residual tastes, odors, disinfection by-products, and free- and combined-chlorine that requires final treatment/removal. Depending on the quality of the incoming water, there are a variety of activated carbon products and solutions that improve water quality for the brewing/bottling industry.
• Activated Carbon and Ion Exchange systems can also used to remove color from malts for use in clear beers and other flavored malt beverages.
• Products that require carbonation typically utilize activated carbon treatment of gases to remove unwanted taste and odors.

Landfill Leachate

• Granular activated carbon (GAC) in combination with biological pretreatment is a leading technology for the treatment of landfill leachate.
• Granular activated carbons remove organic chemicals and reduces toxicity in water to allow safe discharge into groundwater. It is highly effective for odor removal and for the treatment of soluble organic chemicals, pesticides, endocrine disruptors and other contaminants of emerging concern.

Capabilities

• Custom manufacturer of high quality engineered valves & strainers not found in a catalog.
• Standard ANSI designs that meet ASME code requirements.
• VMA – Valve Manufacturers Association of America.
• Exotic Metals such as monel, inconel, 321ss, can be sourced.
• Refactory lined.
• Stellite hardfacing.
• Cryogenic designed valves.
• Onsite repair & consulting.
• 100% made in the USA at their facility in Houston, Texas.

Products

• Butterfly valves
• Check valves
• Gate valves
• Atmospheric relief valves
• Strainers

Testing

• Hydrotesting up to 9000 psig.
• Heat testing up to 1800 F.
• Cryogenic testing to -320 F.
• PMI, magnetic particle, dye penetrant & valve signature testing.
• Design incorporates our chemical & mechanical engineering expertise.

• Valves designed to handle high pressure drops.
• Severe Service Control Trim.
• CCI/BTG Soft Goods.
• Spray Nozzles Stocked.
• Engineered Solutions for all OEM’s.

Filtration Systems

• Treat water for iron, manganese, arsenic, radium, hydrogen sulfide.
• Remove suspended particulates, and other contaminants.
• Plug & Play Greensand Plus Systems
• Horizontal Filters Systems that offer space savings.

Ion Exchange

• Treat water for nitrates, hardness, color, PFA’s, VOC’s.
• Treat other soluble ions.

Demineralization

• High purity applications for power generation, pharmaceutical, semi-conductor.
• Condensate polishing for high temperature applications.

Degasification

• Forced air treats soluble gases like ammonia, CO2, etc.
• Vacuum degasification used for oxygen.

Greensand Media

• Parent company holds the patent for greensand media plus!
• Used by all OEM manufacturers of Greensand filters.

Specialized Systems

• Manganese “mudball” removal.
• Never Clog Underdrain.
• Backwash Reclaim for water conservation.
• High-efficiency water treatment systems.

Products

• Filter Press (Steel, Fiberglass, 304SS, 316SS)
• Rental Units
• Feed Pump Systems
• Conditioning Equipment – Mixing & Blending
• Disposal Systems – Sludge Handling
• Conveyors – Screw & Belt
• Spare Parts & Filter Cloths

Markets Serviced

• Water / Wastewater
• Food & Beverage
• Energy
• Petrochemical
• Laundry & Textitles
• Mining & Minerals

Company Highlights

• 30+ years
• Over 1500 installations in 13 countries
• Premier Product Line of Wasser Filtration

Membrane Process

• Microfilter (MF)
• Ultrafiltration (UF)
• Reverse-Osmosis (RO)
• Container Mounted Options

Ozone Water Sterilization

• Compact Skid Mounted
• Stainless Steel Cabinet

Wastewater Reuse/Minimization

• Membrane Bioreactor (MBR)
• Moving Bed Biofilm Reactor (MBBR)
• Aerobic Sequence Batch Reactor (ASBR)
• Extended Aeration

SCADA Controls

Fiberglass Products:

• FRP Fans
• Ductwork / Piping
• Louvers / Dampers
• Shelters, Enclosures, Booths, Buildings
• Flumes, Catch Basins & Vaults
• Metering Manhole Systems, Manhole Covers
• Ladders, Platforms & Railings
• Tanks, Containers & Covers

Company Highlights

• 70 years in business.
• 50-55 employees, 10 are full-time engineers.

Products

• Launder Covers, Weir Plates, Troughs.
• Baffles, Density Current Baffles.
• Feedwells.
• Insulating Deck Covers.
• Custom Applications.

Protectolite Advantage

• Molded, Reinforced, Thermoset Composites for corrosion resistant, light weight, insulating, high strength applications.
• 3-year standard warrantee with their specifications.
• Extended warrantees up to 5-years upon request.
• Short Lead Times, weeks vs. months from the competition.
• Don’t rely on subcontractors.  Design & manufacturing all done in-house.
• Treated FRP options for extreme caustics or fire-retardant applications.
• CFD analysis, FEA’s, seismic & meteorological calculations done internally within 6-8 weeks.

Products

• Bearing Protection
• Chute Liner Material
• Compression Packing
• Diaphragms for Pumps and Valves
• ePTFE Joint Sealant
• Expansion Joints
• Gaskets
• Hydraulic Components
• Industrial Hose
• Mechanical Seals
• Oil Production Seals
• Pipe Casing Spacers and End Seals
• PTFE Tape
• Rotary Shaft Seals
• Valves
• Wall Penetration Products
• Water Infiltration Sealing Systems

Garlock Brands

• Blue-Gard
• CMG XC
• Gylon
• Klosure
• Link-Seal
• One-Up
• Lubrikup
• PS-Seal
• THERMa-PUR
• TUFF-RAIL

– One of the most versatile and widely used gasket materials available.

– Exceptional sealing properties and conformability, with resitance to creep and cold flow.

– Ideal for many bolted asseblies such as:

• standard flanges
• man ways
• tank covers
• ducting
• heat exchangers

– Performance Features:

• Wide pressure and temperature range
• Unsurpassed chemical compatibility
• Excellent creep and cold flow resistance
• Will not harden or deteriorate with age
• Low coefficient of friction allows easy removal
• Easily conforms to damaged or pitted flanges
• Low compressive load to seal
• Wide adhesive strip for easy installation for all shapes, vertical or horizontal
• Professional engineering support

Fluid Equipment for Water & Wastewater

• Pumps
  • Submersible
  • Non-Clog (see video)
  • High Head
  • High Flow
  • Explosion Proof
• Mixers
• Bar Screen

Company History

• Japanese manufacturer with 104 years of history.
• USA subsidiary opened 35 years ago.
• Approximately 400 stocked pumps in the USA
• Toyota City Success (see video)

High-Efficiency Cross-Flow Microsand Filters

• Superior filtration with patented microsand and injector technologies
• 0.5 micron filtration of suspended solids
• Requires up to 40% less water to backwash than conventional media filters
• One of the smallest footprints of any media filter (up to 3x smaller)
• Side-stream filtration for commercial cooling loops
• Watch Video

V-Series Automatic Screen Filters

• No electric motors, gearboxes, pistons, or switches
• Flush waste is less than 1%
• Only continuous screen filter in the market
• Simple controls and less moving parts
• Low maintenance
• Watch Video

Raw Water Intake Screens

• Over 15,000 installations worldwide.
• Variety of raw water intake screens to meet every application.
• Traveling water screens, stationery water screens, stop logs, grab rakes, bar racks & pumps.
• OEM for aftermarket service, repair and parts for REX and LINK-BELT equipment.
• OEM drawings and specifications for many Envirex, FMC, Siemens, US Filter intake equipment.
• Compliant with US EPA section 316(b) – fish and other life forms are not impinged in the screen.
• Top-side or below-water equipment assessments.

Filtration Systems

• RO/Nanofiltration
• Ultra/Micro Filtration
• Sand Filters
• Regenerative Media
• Disc Filters
• Gravity Sand Filters
• Pressure Filters
• Screw Pump

Elcon Advantages:

• Provide product solutions to the customer with reduced lead time by offering a blended product strategy.
• Ability to offer a turnkey package with installation and bonded insurance.
• Family Owned and flexible business orientation- strong service platform.
• Speed product to market with supply chain options -Elcon can deliver products faster to meet tight delivery schedules.

Elcon Capabilities – Products & Brands:

1. Packaged VFDs – Innomotics, Siemens, Toshiba, ABB, Eaton.
2. Customized MCCs of blended brands – Eaton, Allen Bradley, GE, Siemens
3. Induction motor and starters – US Electrical, Toshiba
4. Synchronous motor excitation systems – Toshiba
5. DC Drive Packaged Systems – ABB
6. Control and E-houses
7. Pump Controls – Made to Order, various brands
8. Compressor Controls – made to Order, various brands
9. HVAC Controls – Toshiba, Honeywell
10. Equipment retrofit packages – Major brands including AB, ABB, Eaton, GE, Siemens Toshiba
11. Wastewater Treatment Plants New and Upgrades – Turnkey
12. Chemical Feed  Packaged Designs – Made to Order
13. SCADA – Allen Bradley, Siemens, Ignition by Inductive automation, GE, Wonderware
14. Telemetry Systems – Made to Order
15. Programming in various protocols – Allen Bradley, Siemens, Modicon, GE and Ignition ( Inductive Automation).
16. Contract manufacturing at our uL certified manufacturing facility. Medium Voltage Electrical and Mechanical assembly preferred, ex. Pneumatic and Hydraulic.

Pump Types

ANSI 73.1, Air Operated Diaphragm, Centrifugal, Canned, Drum, Electric Diaphragm, Fiberglass, Gear, High Pressure, High Purity, Immersible, Inline, Lobe, Machine Coolant, Metering, Peristaltic, Positive Displacement, Progressing Cavity, Sanitary, Sealless, Self Priming, Special Purpose, Submersible, Vacuum, Verderhus Centrifugal, Screw, Vertical Turbine.

Pump Manufacturers

Aquatec, Berkeley, BJM Submersible, Boerger, Camac, Corcoran, Crane-Burks, Crane Crown, Crane Deming, Crane-Weinman, Dean, Eastern, Eclipse, Fybroc, General Pump, Goulds Water Technology, Graymills, Grundfos, Gusher, Haight Gear, Isochem/Pulsafeeder, Iwaki-America, Lewa, Marlow, Micropump, Myers, Nikisso, NOV MOYNO, Paco, Price, Prosser Subersibles, Scot, SPX Johnson, Standard Drum/Tote, STA-RITE, Summit, TonkaFlo, Verder, Yamadaaod, Wanner (Hydra-Cell), Walchem, Vertiflow.

Glycol

• Propylene Glycol
• Ethylene Glycol

Glycol testing of Closed Loops

• Glycol Concentration
• Inhibitor Strength
• Contaminates

Consumable Parts

• Reverse Osmosis (RO) Membranes Elements
• Ultrafiltration (UF) Modules
• Filter Cartridges
• Bag Filters
• Filter Press Cloth

Fasteners:

• Bolts, Nuts, Washers
• Rods, Studs
• Screws, Anchors, Rivets

Alloys include:

• A193 B7, A194, A307, B8, B8M
• Alloy 20, 50, 60
• Aluminum 2024, 6061, Aluminum Bronze
• Avesta, Carpenter
• Brass, Bronze
• Duplex 2205, 2507
• Hastelloy C276, C22
• Haynes
• Inconel 600, 625, 718
• Monel 400, 500, K500
• Silicon Bronze 651, 655
• Stainless 17-4ph, 18.8, 304, 304L, 316, 316L, 410, A286
• Titanium, Zirconium

Plating & Coating Options:

• Chrome
• Black Oxide
• HDG
• Nickel
• Zinc

• For over forty years Fougner Engineered Sales has help source the hard-to-find parts.
• Source hundreds of items from small or obscure manufacturers both domestic and foreign.
• Fougner helps bridge the gap between large customers and large vendors.
• We understand customer service and will place orders your way.

Repair Solutions for:

• Pipe, Valves, Tanks, Troughs, Propellers
• Pumps, Impellers, Shafts
• Ducts, Air Scrubbers
• Heat Exchangers, Chillers, Condensers, Tube Sheets
• Cooling Towers
• Concrete with cracks, joints, coatings
• Metallurgy suffering from chemical attack

Industries Served

• Water/Wastewater
• Power
• Oil, Gas, Petrochemical, Ethanol
• Mining
• Hospitals, Schools, Universities

Key Product Features

• No VOC’s complicating the installation process
• Indefinite shelf life (loaded with stabilizers)
• Extended warranties
• All products sourced in the USA

Company Highlights

• Established 1990 by former Belzona employees.
• Their solutions are used in Marine and Naval industries.
• NSF certified for potable water.
• DuraWrap approved for repairs up to 3,167 psi.  Meets ASME PCC-2-2018, Appendix 401-II for High-Risk Applications

Premium Design Engineering Services for 35 years

• Custom 3D CAD Designs
• 2D Drawing Packages
• Fluid System Designs
• Custom Process Designs
• Complete Facility Designs

Oil & Gas, Power & Cogeneration

• Boiler & Pump Skids
• Pump & Compressor Skids
• Vapor Recovery Systems
• Proven SWD Designs

Water & Wastewater, Beverage, Microelectronics, Healthcare, Pharmaceuticals

• Multi-Media
• UF Systems
• RO Systems

Municipal, Pulp & Paper

• Clarifiers
• Thickeners
